Feature:
- Multi-vehicle compatibility.
- Multiple intelligent detection and protection functions.
- Insert ready to use.
- Reservation charging.
- Real-time detection of charging data.
- The charging gear can be adjusted to protect the battery.
- NFC card activated charging.
- Bluetooth mobile phone control.
- Electric vehicle chargers are suitable for indoor, underground garages, open parking lots and other places.
- Suitable for home and public charging.
Specification:
- Model: NDCDZ-32A
- Rated voltage: 230V AC
- Housing Material: ABS + PC
- Input frequency: 50/60Hz
- Rated current: 32A
- Rated power: 7KW
- Operating current: 16A/32A (Adjustable)
- Display mode: LED indicator +2.8 inch LCD display
- Cable length: 5m
- Operating temperature: -30℃ ~ +50℃
- Operating humidity: 5% ~ 95% non-condensing
- Altitude: ≤3000m
- Connector Type: Type 2
- Protection class: IP65
- Installation method: Wall hanging/Floor type
- Safety protection: Scram protection, Grounding protection, Leakage protection, Overvoltage protection, Undervoltage protection, etc.
- Control: RFID, Mobile Application, Remote Control
- Design standard: IEC 61851-1/IEC 62196/IEC 60664-1/IEC 61000/EN 301489-1
Pakcing List
- 1x EV Charging Station Wallbox
- 10x Screws
- 10x Dowels
- 2x RFID Cards
Note:
- For the first installation, attention should be paid to the power cable according to IN-L (fire), IN-N (zero), PE (ground) one by one, and the fire wire and zero wire cannot be reversed.
- PE (ground wire) needs to be grounded reliably.
- Make sure that the emergency stop switch is activated after power is supplied.
- Before charging, make sure that the tip of the charging gun is free from stains and water.
- Please do not dissemble the device by yourself under any circumstances.
- If you have any other questions, please feel free to contact us.
- Installation attention:This goods should be paid to the power cable according to IN-L (fire), IN-N (zero), PE (ground) one by one, and the fire wire and zero wire cannot be reversed.
